Citymaster 650

Key Features of the Citymaster 650

  • Front coupling triangle for attachments – No Tools Required
  • Comfort steering column and adjustable seat options available
  • Permanent all-wheel drive to combat vast terrains in the 2t class
  • Travel speed of up to 25 km/h
  • Articulated steering for improved manoeuvrability
  • 600 litre universal hopper made of seawater-resistant aluminium alloy
  • Machine Functions are comfortably controlled via the integrated one handed operating system in the armrest
  • Hako-Fleet-Management (Telematics Website) is an available option for all Citymaster 650 cleaning machines
  • The Citymaster 650 meets the emission limit requirements of the Stage V exhaust emission standard
Or Call us on 01788 825600
Description

The basic version of the Citymaster 650, designed as a compact implement carrier, already sets new standards in the 2-t class: for example with articulated steering, permanent all-wheel drive with a fully electronic control system and extensive features providing increased comfort and safety at work.

Thanks to its multi-functional design, the Citymaster 650 can be retooled quickly and easily, for example as a professional sweeper or an efficient snowplough for winter service tasks, which makes this machine not only extremely versatile in use but also particularly economical as it provides multiple application options.

Freedom through flexibility

Working in the city comes with a wide range of different demands posed on Municipal Technology equipment – and these demands change with the seasons. The Citymaster 650 meets all seasonal requirements with its small vehicle width, directionally stable steering and a small turning circle ensuring excellent manoeuvrability in confined areas. In addition, the vehicle’s multi-functional design ensures economically efficient use all year round.

Reduces fuel consumption and emissions

The Citymaster 650 meets the emission limit requirements of the Stage V Exhaust Emission Standard. Clever details such as the energy-saving drive control system and three different performance levels reduce the machine’s fuel consumption both in work mode and during road travel.

Multipurpose use through multi-functionality

The Citymaster 650 is a versatile implement carrier and professional sweeper all in one. Thanks to four attachment interfaces allowing the combined use of different attachments and superstructures, the machine can carry out a wide range of additional tasks: for example winter service, green area maintenance or wet cleaning tasks. You only need one machine instead of several special vehicles – which is both more efficient and economical.

Technical Data

Technical Data for Basic VehicleCitymaster 650
Engine and driveEngine• Water-cooled 3-cylinder industrial Diesel engine with 1,642 cc
• DOC and DPF, output 25.5 kW at 2,630 rpm
• Common-rail direct fuel injection, tank capacity 41 litres
• Engine stays below the limit values according to the Emission Standard 2016 / 1628 /EC Stage V
Approval • EU type approval for the basic unit as a tractor T2a (LoF) (agricultural and forestry machine)
Ground drive• Traction- and energy-efficiency-optimised hydro-static ground drive with permanent all-wheel drive
• Drive control system with automatic load control in transport mode
• 3-stage fixed speed in work-travel mode (1,900 rpm [ECO] – 2,250 rpm [Standard] – 2,630 rpm [MAX])
Hydraulics• High pressure hydraulics with variable output distribution for rotary consumers
• Circuit 1 (front) 27 / 31 / 37 I/min @ 195 bar
• Circuit 2 (rear) 21 / 25 / 29 I/min @ 195 bar
• 1 hydraulic circuit at the front, 1 hydraulic circuit at the rear
Driving and working characteristicsSpeed
• Automotive driving speed 0–25 km/h
• Hydro-static work-travel speed 0–25 km/h
• Reversing 0–12 km/h
Steering and chassis• Hydraulically steered, articulated 4-wheel chassis; steering angle 53°
• Robust articulated joint with integrated pendulum compensation and roll stability control system
Brake• Hydro-static brake acting on all four wheels, service brake at the rear
• Mechanical parking brake acting on the rear wheels
Tyres• 270/50-12 comfort tyres
• 23 x 10.50-12 lawn tyres
• 23 x 8.50-12 standard tyres
Cabin• 1-seater comfort cabin with comfort driver’s seat and operating panel integrated in the armrest
• Central display shows all machine functions, adjustable steering column
• Hot-water heating and optional air conditioning
• Frame doors with sliding windows
• Foldable wing mirrors, adjustable from inside the cabin
Dimensions (H/W/L)Basic unit: 1,970 mm x 1,210 x 3,830 mm (standard tyres, without tow bar)
Sweeper: 1,970 mm x 1,210 x 4,510/5,170 mm (standard tyres 2B/3B)
Load data Empty weight
1,430 kg (implement carrier), 1,780 kg (sweeper)
Permissible values
Total weight 2,200 kg, axle load 1,200/1,500 kg (front/rear)
DimensionsH/W/L Basic unit: see brochure
Sweeper: 1,980 x 1,090 x 3,900 mm (standard tyres 2B)
Wheelbase 1,270 mm
Track width 866 mm
Inner turning radius1,390 mm
Purchase Options

OUTRIGHT PURCHASE

Hako Machines have a number of flexible purchase options to suit your needs, one of which is outright purchase. No deposit is required and upon receipt of a purchase order and the opening of a credit account, flexible payment terms can be offered. Once opened, a credit account can be used to purchase parts on account.

Our machines come with a warranty period of either 12 months or working hours depending on the equipment and whichever comes first.

If you feel that outright purchase is the right option for your business needs, Hako Machines can also offer a comprehensive range of service packages to ensure that your machine is maintained by our factory trained engineers.

RENTAL

Through our Finance Partner PMD Leasing, we are able to offer attractive Rental/Contract Hire packages. Benefits include;

  • Renting it over a period in return for fixed rental payments allows you to free up working capital for use in other areas
  • You don’t have to pay the full cost of the asset up front, so you don’t use up your cash or have to borrow money
  • You have access to a higher standard of equipment, which might be too expensive for you to buy outright
  • You pay for the asset over the fixed period of time that you use it, which helps you budget for the future
  • The business can usually deduct the full cost of lease rentals from taxable income
  • You do not have to worry about maintenance and breakdowns
  • Should circumstances change, upgrades to the equipment are available
  • After the initial term of the agreement, the ageing asset can either be returned or extended to suit needs at that time

SHORT-TERM HIRE

A selection of ‘Spot-hire’ machines are available upon request to assist with;

  • Emergency cleaning requirements or ad-hoc deep cleaning
  • Cover for breakdown machines
  • Cover for new machine deliveries
  • ‘Try before you buy’

Availability is not guaranteed and a short term hire document will be required before the hire commences. Flexible terms are available depending upon your needs.

The basic version of the Citymaster 650, designed as a compact implement carrier, already sets new standards in the 2-t class: for example with articulated steering, permanent all-wheel drive with a fully electronic control system and extensive features providing increased comfort and safety at work.

Thanks to its multi-functional design, the Citymaster 650 can be retooled quickly and easily, for example as a professional sweeper or an efficient snowplough for winter service tasks, which makes this machine not only extremely versatile in use but also particularly economical as it provides multiple application options.

Freedom through flexibility

Working in the city comes with a wide range of different demands posed on Municipal Technology equipment – and these demands change with the seasons. The Citymaster 650 meets all seasonal requirements with its small vehicle width, directionally stable steering and a small turning circle ensuring excellent manoeuvrability in confined areas. In addition, the vehicle’s multi-functional design ensures economically efficient use all year round.

Reduces fuel consumption and emissions

The Citymaster 650 meets the emission limit requirements of the Stage V Exhaust Emission Standard. Clever details such as the energy-saving drive control system and three different performance levels reduce the machine’s fuel consumption both in work mode and during road travel.

Multipurpose use through multi-functionality

The Citymaster 650 is a versatile implement carrier and professional sweeper all in one. Thanks to four attachment interfaces allowing the combined use of different attachments and superstructures, the machine can carry out a wide range of additional tasks: for example winter service, green area maintenance or wet cleaning tasks. You only need one machine instead of several special vehicles – which is both more efficient and economical.


Technical Data for Basic VehicleCitymaster 650
Engine and driveEngine• Water-cooled 3-cylinder industrial Diesel engine with 1,642 cc
• DOC and DPF, output 25.5 kW at 2,630 rpm
• Common-rail direct fuel injection, tank capacity 41 litres
• Engine stays below the limit values according to the Emission Standard 2016 / 1628 /EC Stage V
Approval • EU type approval for the basic unit as a tractor T2a (LoF) (agricultural and forestry machine)
Ground drive• Traction- and energy-efficiency-optimised hydro-static ground drive with permanent all-wheel drive
• Drive control system with automatic load control in transport mode
• 3-stage fixed speed in work-travel mode (1,900 rpm [ECO] – 2,250 rpm [Standard] – 2,630 rpm [MAX])
Hydraulics• High pressure hydraulics with variable output distribution for rotary consumers
• Circuit 1 (front) 27 / 31 / 37 I/min @ 195 bar
• Circuit 2 (rear) 21 / 25 / 29 I/min @ 195 bar
• 1 hydraulic circuit at the front, 1 hydraulic circuit at the rear
Driving and working characteristicsSpeed
• Automotive driving speed 0–25 km/h
• Hydro-static work-travel speed 0–25 km/h
• Reversing 0–12 km/h
Steering and chassis• Hydraulically steered, articulated 4-wheel chassis; steering angle 53°
• Robust articulated joint with integrated pendulum compensation and roll stability control system
Brake• Hydro-static brake acting on all four wheels, service brake at the rear
• Mechanical parking brake acting on the rear wheels
Tyres• 270/50-12 comfort tyres
• 23 x 10.50-12 lawn tyres
• 23 x 8.50-12 standard tyres
Cabin• 1-seater comfort cabin with comfort driver’s seat and operating panel integrated in the armrest
• Central display shows all machine functions, adjustable steering column
• Hot-water heating and optional air conditioning
• Frame doors with sliding windows
• Foldable wing mirrors, adjustable from inside the cabin
Dimensions (H/W/L)Basic unit: 1,970 mm x 1,210 x 3,830 mm (standard tyres, without tow bar)
Sweeper: 1,970 mm x 1,210 x 4,510/5,170 mm (standard tyres 2B/3B)
Load data Empty weight
1,430 kg (implement carrier), 1,780 kg (sweeper)
Permissible values
Total weight 2,200 kg, axle load 1,200/1,500 kg (front/rear)
DimensionsH/W/L Basic unit: see brochure
Sweeper: 1,980 x 1,090 x 3,900 mm (standard tyres 2B)
Wheelbase 1,270 mm
Track width 866 mm
Inner turning radius1,390 mm
